Introduction
Semiconductor manufacturing is a complex, high-precision process that requires a wide range of specialized equipment. From wafer fabrication and photolithography to etching, deposition, testing, and metrology, each step in the process relies on advanced tools designed and produced by dedicated equipment manufacturers.
These chip equipment companies play a fundamental role in enabling the development and production of integrated circuits across logic, memory, analog, and power semiconductor segments. As device geometries continue to shrink and the demand for performance and efficiency increases, the importance of equipment capability and innovation has grown accordingly.
This article provides an overview of ten leading global chip equipment manufacturers. While the list is not ranked, each company included has a significant market presence and contributes essential technologies to the semiconductor manufacturing value chain.
1. SCREEN Semiconductor Solutions (Japan)
Company Overview
SCREEN Semiconductor Solutions Co., Ltd. is a key subsidiary of SCREEN Holdings Co., Ltd., one of Japan’s most established and technology-driven industrial groups. With a legacy tracing back to 1943, SCREEN Semiconductor Solutions has become a global leader in wafer cleaning and wet processing equipment, offering essential front-end process tools used in semiconductor manufacturing. Headquartered in Kyoto, Japan, the company delivers highly specialized equipment that supports both logic and memory chip production at advanced process nodes.
SCREEN’s technologies are critical for ensuring wafer surface quality and process uniformity, particularly in high-precision applications such as 3D NAND, DRAM, FinFET, and GAA architectures. Its tools are widely adopted across the world’s most advanced semiconductor fabs, providing consistent, contamination-free performance during critical process stages.
With a strong focus on wet cleaning, coating, and developing systems, SCREEN has built a reputation for innovation and reliability. The company also invests heavily in process development to meet the evolving needs of next-generation semiconductors, while maintaining a robust presence in the Asia-Pacific, U.S., and European markets.
Brief History and Background of the Company
SCREEN Semiconductor Solutions was formally established in 2014 following a reorganization of the semiconductor equipment segment within Dainippon Screen Mfg. Co., Ltd. However, its experience and IP in semiconductor tools span several decades. As part of the larger SCREEN Holdings Group, the company benefits from a heritage of precision engineering, with its first photolithography and wet cleaning systems introduced as early as the 1970s.
Today, SCREEN operates globally, offering solutions to many of the top-tier IDMs and foundries. It continues to play a pivotal role in enabling smaller feature sizes and higher integration density through reliable wet processing and cleaning technologies.
Overview of Products and Services
SCREEN Semiconductor Solutions focuses on the following equipment categories:
-
Single-Wafer Cleaning Systems: Advanced cleaning platforms for critical process steps such as post-etch and post-CMP cleaning.
-
Batch Wafer Cleaning Systems: High-throughput tools for cleaning large volumes of wafers while ensuring particle control and uniformity.
-
Coaters/Developers: Tools for photolithography processes, including coating and development stages.
-
Plating Systems: Equipment for copper and advanced packaging applications.
-
Service and Support: Comprehensive global maintenance, training, and parts support for fab continuity.
These tools are essential for achieving defect-free surfaces, critical dimension control, and process stability in sub-10nm and 3D chip manufacturing.
Notable Achievements or Recognitions
-
Recognized globally for excellence in single-wafer cleaning systems and batch processing tools.
-
Long-standing technology partner with major foundries and memory makers in Asia, Europe, and North America.
-
Significant contributions to cleaning technologies for FinFET, 3D NAND, and EUV lithography readiness.
-
Regularly ranked among the top 10 global semiconductor equipment suppliers by revenue.
-
Strong focus on sustainability through reduced chemical usage and water consumption in wafer cleaning processes.
Company Details
| Information | Value |
|---|---|
| Website | https://www.screen.co.jp/ |
| Type of Business | Semiconductor Wafer Cleaning and Wet Processing Equipment Manufacturer |
| Location (Headquarters) | Kyoto, Japan |
| Year Established | 2014 (with roots tracing back to 1943) |
| Main Markets | Japan, South Korea, Taiwan, China, United States, Europe |
2. Hitachi High-Tech Corporation (Japan)
Brief History and Background of the Company
Hitachi High-Tech Corporation, a core subsidiary of Hitachi, Ltd., was established in 2001 through the integration of several business units within the Hitachi Group. Headquartered in Tokyo, Japan, the company is known for delivering advanced technologies across a broad spectrum of industries, including healthcare, life sciences, and electronics. In the semiconductor sector, Hitachi High-Tech plays a vital role in the front-end manufacturing process, with its specialized solutions for metrology and inspection. Backed by decades of research and innovation, the company has built a strong reputation for high-precision tools that meet the stringent requirements of leading semiconductor fabs around the world.
Overview of Products and Services
Hitachi High-Tech's Semiconductor Process Control Systems Division offers an extensive portfolio of high-resolution inspection and metrology tools that are critical in the production of advanced semiconductor devices. Key product categories include:
-
Critical Dimension Scanning Electron Microscopes (CD-SEM): Industry-leading systems that deliver nanometer-scale measurement accuracy for line widths, spacing, and other micro-patterned features.
-
Defect Review and Analysis Tools: Solutions designed for identifying, categorizing, and analyzing defects at various layers of the wafer stack.
-
Metrology Equipment: Precision tools for monitoring wafer topography, film thickness, and critical parameters essential for yield management.
-
Advanced Lithography Support: Complementary systems that support EUV and multi-patterning processes in next-generation chip production.
-
Global Service and Support: A robust network that ensures tool uptime and performance optimization across customer sites.
These technologies enable fabs to detect and control nanoscale variations that impact device performance and yield, particularly in the sub-5nm process node era.
Notable Achievements or Recognitions
-
Recognized as a global leader in CD-SEM and metrology systems, frequently used in top-tier logic and memory fabs.
-
Close technical collaborations with major foundries and IDMs in Asia, Europe, and the United States.
-
Pioneered several generations of high-resolution SEM tools tailored for advanced process nodes including EUV lithography.
-
Known for unmatched measurement repeatability and system stability, enabling consistent process control in high-volume manufacturing environments.
-
Active contributor to international semiconductor equipment standardization and R&D consortiums.
Company Details
| Information | Value |
|---|---|
| Website | https://www.hitachi-hightech.com/ |
| Type of Business | Semiconductor Metrology and Inspection Equipment Manufacturer |
| Location (Headquarters) | Tokyo, Japan |
| Year Established | 2001 |
| Main Markets | Japan, Taiwan, South Korea, China, United States, Europe |
3. Tokyo Electron Limited (TEL) (Japan)
Company Background
Tokyo Electron Limited (TEL) is a prominent Japanese manufacturer of semiconductor and flat panel display (FPD) production equipment. Founded in 1963, the company is headquartered in Tokyo, Japan, and has established a strong global presence with manufacturing, R&D, and customer support facilities across Asia, North America, and Europe.
TEL’s product offerings cover a wide range of core front-end wafer processing technologies. Its main product lines include etching systems, coating/developing equipment, and thermal processing tools. These systems are used by leading semiconductor foundries and IDMs for advanced node production and high-volume manufacturing.
One of the company’s strategic strengths lies in its focus on system integration, energy efficiency, and process stability. TEL’s commitment to reducing energy consumption and improving system throughput has made its tools increasingly valuable in modern fabs striving for sustainable production and operational excellence.
TEL is widely regarded as a key contributor to the semiconductor supply chain, especially in the Asia-Pacific region, where it maintains significant market share and long-term partnerships with major chipmakers. The company’s robust engineering capabilities and high-quality equipment have earned TEL multiple awards and recognitions from leading industry organizations and customers.
Products and Capabilities
TEL’s semiconductor equipment portfolio includes:
-
Etching Systems: Critical for precise material removal and pattern definition.
-
Coating/Developing Systems: Used for photoresist application and development in lithography processes.
-
Thermal Processing Systems: Enable oxidation, annealing, and diffusion with uniform temperature control and energy efficiency.
These tools are designed to meet the needs of both leading-edge and mature semiconductor nodes, offering scalability, high yield, and reduced environmental impact.
| Information | Value |
|---|---|
| Website | https://www.tel.com |
| Type of Business | Semiconductor Equipment Manufacturer |
| Location (Headquarters) | Tokyo, Japan |
| Year Established | 1963 |
| Main Markets | Asia-Pacific, North America, Europe |
4. ASML (Netherlands)
Company Overview and Background
ASML, headquartered in Veldhoven, Netherlands, is a global leader in the design and manufacture of photolithography equipment used in semiconductor fabrication. Established in 1984 as a joint venture between Philips and ASM International, the company has grown to become one of the most critical suppliers in the semiconductor industry. It is the only company in the world currently offering extreme ultraviolet (EUV) lithography systems—an essential technology for producing advanced node chips.
ASML’s core product lines include EUV and deep ultraviolet (DUV) lithography systems. These tools enable semiconductor manufacturers to pattern the intricate circuits required for modern chips. The company's EUV systems are vital for the production of chips at advanced process nodes such as 7nm, 5nm, and 3nm, and are integral to the manufacturing strategies of leading foundries and integrated device manufacturers (IDMs).
ASML is widely recognized for its consistent R&D investment, supply chain coordination, and technological innovation. It plays a pivotal role in the advancement of Moore's Law by enabling further miniaturization and performance gains in semiconductor devices.
Key Technologies and Industry Role
ASML’s EUV lithography systems utilize light at a 13.5nm wavelength to achieve extremely fine pattern resolutions, enabling the mass production of chips at nodes below 7nm. Its DUV systems continue to be used in mature nodes and are an essential part of multi-patterning strategies.
ASML’s tools are employed by virtually all major semiconductor manufacturers, including TSMC, Intel, and Samsung. The company’s ability to deliver both cutting-edge technology and production-scale reliability has cemented its position as a strategic supplier in the global semiconductor supply chain.
| Information | Value |
|---|---|
| Website | https://www.asml.com |
| Type of Business | Semiconductor Equipment Manufacturer |
| Location (Headquarters) | Veldhoven, Netherlands |
| Year Established | 1984 |
| Main Markets | Global – Focus on Asia, Europe, and North America |
5. Lam Research (USA)
Company Profile
Lam Research Corporation is a leading U.S.-based provider of wafer fabrication equipment and services to the global semiconductor industry. Founded in 1980 and headquartered in Fremont, California, Lam Research has become one of the foremost innovators in semiconductor process technology, particularly in plasma etching and thin film deposition.
Lam’s tools play a critical role in enabling advanced semiconductor architectures such as FinFET, 3D NAND, and gate-all-around (GAA) transistors. The company is known for collaborating closely with global chip manufacturers to deliver solutions that support high aspect ratio structures and atomic-level precision. Its commitment to technology leadership and process integration has made Lam a key partner in cutting-edge fabs around the world.
Over the years, Lam Research has introduced numerous breakthroughs in dry etching and atomic layer deposition (ALD), enabling chipmakers to scale device features while maintaining performance and yield. Its solutions are indispensable in logic, memory, and advanced packaging applications.
Overview of Products and Services
Lam Research specializes in:
-
Plasma Etch Systems: Advanced tools for pattern transfer in logic and memory processes.
-
Thin Film Deposition: Atomic layer deposition (ALD) and chemical vapor deposition (CVD) systems that enable conformal coating and precise thickness control.
-
Clean and Strip Systems: Wet and dry solutions for photoresist removal and wafer cleaning.
-
Customer Support Services: Global technical support, predictive maintenance, and equipment upgrades.
These products are widely adopted in semiconductor fabs operating at advanced nodes, including 5nm, 3nm, and emerging sub-2nm technologies.
Notable Achievements or Recognitions
-
Recognized as a key contributor to 3D NAND and FinFET scaling technologies.
-
Multiple industry awards for innovation and manufacturing excellence.
-
Included in Fortune 500 and consistently ranked among the top global semiconductor equipment suppliers.
-
Strong focus on sustainability, including reduced process energy consumption and environmental impact.
Company Details
| Information | Value |
|---|---|
| Website | https://www.lamresearch.com |
| Type of Business | Semiconductor Equipment Manufacturer |
| Location (Headquarters) | Fremont, California, USA |
| Year Established | 1980 |
| Main Markets | North America, Asia-Pacific, Europe |
6. KLA Corporation (USA)
Company Overview
KLA Corporation is a U.S.-based semiconductor equipment company specializing in process control, defect inspection, and yield management technologies. Founded in 1975 and headquartered in Milpitas, California, KLA plays an essential role in ensuring the performance and reliability of semiconductor wafers throughout the fabrication process.
The company’s core competencies lie in advanced metrology and inspection systems that enable chip manufacturers to detect nanoscale defects and monitor critical process parameters in real time. These solutions are integral to achieving high yield and process uniformity in advanced node manufacturing, especially below the 7nm threshold.
KLA has developed strong, long-term partnerships with global foundries and integrated device manufacturers (IDMs), providing tailored process control solutions that align with specific device architectures and yield goals. Its innovative product platforms support a wide array of semiconductor applications, including logic, memory, and packaging technologies.
Brief History and Background of the Company
Established in 1975, KLA was originally formed through the merger of KLA Instruments and Tencor Instruments in 1997, a strategic move that combined industry-leading expertise in inspection and metrology. Over the years, KLA has grown through both organic development and acquisitions, solidifying its position as a global leader in process control systems for the semiconductor industry.
Overview of Products and Services
KLA’s product portfolio includes:
-
Defect Inspection Systems: Tools that detect particles and pattern defects on wafers and masks at multiple process stages.
-
Metrology Systems: Equipment for measuring critical dimensions, overlay, film thickness, and more with sub-nanometer precision.
-
Yield Management Software: Data analysis platforms that enable predictive diagnostics and real-time process optimization.
-
Service & Support: Comprehensive customer support and field service programs for global fabs.
These solutions help chipmakers maintain production efficiency, enhance yield, and accelerate time-to-market for new semiconductor devices.
Notable Achievements or Recognitions
-
Global leader in process control and metrology technologies.
-
Key enabler of advanced technology nodes including 3nm and 2nm.
-
Recognized by major foundries for contributions to yield enhancement and defect mitigation.
-
Listed on the NASDAQ 100 and consistently ranked among top U.S. semiconductor equipment firms.
-
Strong track record in R&D investment and technology innovation.
Company Details
| Information | Value |
|---|---|
| Website | https://www.kla.com |
| Type of Business | Semiconductor Process Control Equipment Manufacturer |
| Location (Headquarters) | Milpitas, California, USA |
| Year Established | 1975 |
| Main Markets | North America, Asia-Pacific, Europe |
7. Advantest (Japan)
Brief History and Background of the Company
Advantest Corporation is a globally recognized leader in automatic test equipment (ATE) for the semiconductor industry. Founded in 1954 and headquartered in Tokyo, Japan, the company initially focused on electronic measuring instruments before shifting its emphasis to semiconductor testing systems in the 1970s. Over the decades, Advantest has evolved into one of the most important contributors to back-end semiconductor manufacturing, offering state-of-the-art testing solutions for advanced logic and memory devices.
With continuous investments in R&D and strategic acquisitions, such as the purchase of Verigy in 2011, Advantest has broadened its technology scope and solidified its market position, particularly in high-performance computing (HPC), 5G, and artificial intelligence (AI) chip testing. Today, the company’s equipment supports leading IDMs and foundries in delivering quality and reliability across complex semiconductor designs.
Overview of Products and Services
Advantest provides a comprehensive range of ATE systems tailored for different testing requirements, including:
-
SoC Test Systems: Flagship platforms such as the V93000 Series, widely used in testing application processors, RF chips, and other system-on-chip devices.
-
Memory Test Systems: High-efficiency testers for DRAM and NAND flash memory, supporting next-gen memory standards like DDR5 and LPDDR5.
-
Handler & Device Interface Solutions: Equipment that facilitates seamless device handling and integration with test systems in high-volume production.
-
Test Cell Automation: Complete test cell ecosystems including testers, handlers, and control software for smart factories.
-
Field Services & Support: Global service network offering calibration, upgrades, and training for customer teams.
These solutions are instrumental in reducing time-to-market, improving test accuracy, and lowering total cost of ownership for customers operating in complex semiconductor markets.
Notable Achievements or Recognitions
-
Global market leader in SoC and memory ATE systems, consistently ranked among the top in the ATE sector by market share.
-
Strong presence in HPC, automotive, 5G, and AI-related chip testing.
-
Pioneered advanced testing platforms that support multi-site and parallel testing to optimize throughput.
-
Integrated automation and smart factory solutions aligned with Industry 4.0.
-
Recipient of multiple supplier excellence awards from major IDMs and fabless semiconductor firms.
Company Details
| Information | Value |
|---|---|
| Website | https://www.advantest.com |
| Type of Business | Semiconductor Test Equipment Manufacturer |
| Location (Headquarters) | Tokyo, Japan |
| Year Established | 1954 |
| Main Markets | Japan, South Korea, Taiwan, China, United States, Europe |
8. Applied Materials (USA)
Company Profile and Background
Applied Materials, Inc., headquartered in Santa Clara, California, is one of the largest and most influential semiconductor equipment manufacturers in the world. Founded in 1967, the company has built a robust global presence through continuous innovation and strategic expansion. Applied Materials provides manufacturing equipment, services, and software used in the production of semiconductor chips for virtually all device types and applications.
With decades of experience, the company delivers end-to-end process solutions spanning deposition, etching, metrology, and chemical mechanical planarization (CMP). Its technologies support advanced fabrication processes for logic and memory devices as well as advanced packaging and display manufacturing. Applied Materials’ comprehensive product portfolio enables chipmakers to improve yield, performance, and power efficiency while scaling to smaller geometries.
The company’s consistent investment in research and development, combined with strategic partnerships across the semiconductor ecosystem, has positioned it as a global technology leader. Notable achievements include the development of materials engineering innovations that support advanced transistor architectures such as FinFET and gate-all-around (GAA) structures.
Product Focus and Technological Strength
Applied Materials specializes in core front-end semiconductor processes, including:
-
Deposition: Tools for physical vapor deposition (PVD), chemical vapor deposition (CVD), and atomic layer deposition (ALD).
-
Etching: High-precision systems for pattern transfer across metal and dielectric layers.
-
Metrology and Inspection: Integrated solutions for wafer inspection, critical dimension measurement, and defect analysis.
-
CMP (Chemical Mechanical Planarization): Equipment for planarizing wafer surfaces, crucial for multilayer integration.
These capabilities are deployed across logic, DRAM, NAND, and heterogeneous integration platforms, enabling consistent performance in both mature and cutting-edge manufacturing nodes.
| Information | Value |
|---|---|
| Website | https://www.appliedmaterials.com |
| Type of Business | Semiconductor Equipment Manufacturer |
| Location (Headquarters) | Santa Clara, California, USA |
| Year Established | 1967 |
| Main Markets | North America, Asia-Pacific, Europe |
9. Teradyne (USA)
Brief History and Background of the Company
Teradyne, Inc., founded in 1960 and headquartered in North Reading, Massachusetts, is one of the most established providers of automated test equipment (ATE) in the semiconductor industry. The company began by supplying test systems for diodes and transistors and has grown into a global leader in test solutions that ensure the performance, quality, and reliability of modern electronics. Over time, Teradyne has expanded its scope from traditional semiconductor testing to broader industrial automation, including robotics and smart factory technologies.
With a focus on innovation, Teradyne plays a critical role in the final test phase of integrated circuit (IC) manufacturing, where functionality and performance are validated before market deployment. Their test systems are widely adopted across high-growth sectors such as mobile communications, automotive electronics, consumer electronics, and IoT devices.
Overview of Products and Services
Teradyne offers a range of solutions tailored to the evolving needs of semiconductor and electronics manufacturers, including:
-
SoC Test Systems: High-throughput ATE for testing complex system-on-chip devices, including wireless and mixed-signal components.
-
Memory Test Systems: Tools that handle parallel testing of memory ICs such as DRAM and NAND, ensuring speed and data retention reliability.
-
Wireless Test Systems: Support for testing RF components in mobile and connectivity devices.
-
Automotive and Power Device Testers: Systems specialized for the rigorous testing of power semiconductors and automotive-grade electronics.
-
Automation and Robotics: Through acquisitions like Universal Robots and MiR, Teradyne extends its portfolio to collaborative robots (cobots) and autonomous mobile robots (AMRs).
-
AI-Driven Diagnostics and Test Automation: Advanced software platforms for predictive analytics, failure analysis, and adaptive test algorithms.
Teradyne’s comprehensive test platforms are valued for their scalability, precision, and support for next-generation silicon technologies.
Notable Achievements or Recognitions
-
Recognized as a global ATE leader, consistently ranking among the top vendors in terms of revenue and market share.
-
Leading provider of test solutions for 5G, AI processors, and automotive semiconductor markets.
-
Strong R&D investment in AI-driven test diagnostics and machine learning integration.
-
Strategic partnerships with leading IDMs, OSATs, and fabless semiconductor firms worldwide.
-
Expansion into industrial automation has positioned the company as a key player in smart manufacturing initiatives globally.
Company Details
| Information | Value |
|---|---|
| Website | https://www.teradyne.com |
| Type of Business | Automated Test Equipment Manufacturer |
| Location (Headquarters) | North Reading, Massachusetts, USA |
| Year Established | 1960 |
| Main Markets | United States, China, South Korea, Taiwan, Japan, Europe |
10. Canon Inc. (Japan)
Focused View on Canon’s Semiconductor Equipment Division
Brief History and Background of the Company
Canon Inc., founded in 1937 and headquartered in Tokyo, Japan, is globally recognized for its imaging and optical technologies. While widely known for its cameras and office equipment, Canon also operates a specialized semiconductor lithography equipment division, which plays a critical role in the production of semiconductor devices. Canon entered the lithography market in the 1970s, focusing on optical alignment and projection systems. Over the years, the company has concentrated its lithography development efforts on Deep Ultraviolet (DUV) steppers and scanners optimized for mature and specialty nodes. Canon’s strength lies in providing cost-effective and precise patterning solutions, especially for applications where extreme miniaturization is not required, such as IoT chips, power devices, and analog ICs.
Overview of Products and Services
Canon’s semiconductor equipment division specializes in DUV lithography systems, particularly i-line and KrF scanners, used for patterning features in the 130 nm to 350 nm range. These systems are widely adopted in the production of:
-
Power semiconductors
-
MEMS and sensors
-
Display driver ICs
-
Microcontrollers for IoT applications
The company also offers FPA (Fine Pattern Aligner) series and steppers designed for high overlay accuracy, productivity, and flexibility across a variety of substrates. Canon continues to develop its lithography portfolio with a focus on compact, energy-efficient systems and user-friendly operation, which are ideal for specialty fabs and R&D environments.
Notable Achievements or Recognitions
-
A global leader in DUV lithography for mature-node production lines.
-
Maintains a strong market share in analog, RF, and power IC manufacturing.
-
Continues to support sustainable manufacturing goals through energy-efficient tool designs.
-
Offers competitive solutions for cost-sensitive semiconductor fabs and foundries with diverse product mixes.
-
Collaborates with academic institutions and niche semiconductor firms to tailor tools for unique manufacturing needs.
Company Details
| Information | Value |
|---|---|
| Website | https://global.canon/ |
| Type of Business | Semiconductor Lithography Equipment Manufacturer |
| Location (Headquarters) | Tokyo, Japan |
| Year Established | 1937 |
| Main Markets | Japan, Taiwan, China, South Korea, Europe, United States |
Conclusion
How can the semiconductor industry continue advancing at the pace demanded by modern technology? The answer lies in the combined expertise of the world’s leading chip equipment manufacturers.
Each company profiled in this article brings a unique specialization—from EUV lithography and atomic layer deposition to advanced metrology and process control. Together, they form a deeply interconnected ecosystem that enables innovation across every stage of semiconductor manufacturing.
As fabs push toward sub-2nm nodes, adopt AI-driven automation, and invest in advanced packaging, collaboration among equipment vendors, foundries, and research institutions becomes more critical than ever. No single company can address all challenges alone—success depends on seamless integration of tools and technologies across regions and disciplines.
Fortunately, these top manufacturers have a strong track record of driving breakthroughs that redefine what's possible. Their tools support everything from edge computing and automotive chips to the most advanced logic devices powering AI infrastructure.
By delivering precision, reliability, and innovation, these equipment leaders continue to play a foundational role in shaping the future of the global semiconductor landscape. For industry professionals, staying aligned with their advancements is essential to staying competitive in a rapidly evolving market.
