1. Introduction

Wafer-level electrical characterization relies heavily on the accuracy and reliability of probing. As semiconductor devices move toward higher frequencies, lower power consumption, and smaller geometries, the type of probe used in on-wafer testing becomes critical.

Although all probes perform the same fundamental function—creating a temporary electrical connection between the tester and the device—DC probes, RF probes, and microwave probes are engineered for very different electrical environments.

Choosing the wrong probe type can cause

• ● signal distortion

• ● unstable contact resistance

• ● inaccurate S-parameter measurements

• ● repeatability loss

• ● probe damage or pad damage

This article provides a professional, accurate, and complete technical comparison for engineers selecting probes for parametric test, RF characterization, or mmWave applications.

2. What Are DC, RF, and Microwave Probes? — A Quick Overview

Now let’s analyze each type in detail.

3. DC Probes

3.1 Purpose & Use Cases

DC probes are used for static or low-frequency electrical measurements, including:

• ● IV characterization

• ● CV curve tracing

• ● Breakdown voltage measurement

• ● Leakage current measurement

• ● Reliability testing (HTOL, WLR, HCI)

• ● Material characterization

They are widely used on wafer probe stations in semiconductor fabs, research labs, and FA labs.

3.2 Structure

A typical DC probe includes:

• ● Tungsten or beryllium-copper tip

• ● Shank with high stiffness

• ● Coaxial or triaxial cable (for low-leakage or guarded measurements)

• ● Probe body that mounts to the probe manipulator

DC probes usually have sharp taper tips (e.g., 3 µm–10 µm radius) for contacting small pads.

3.3 Electrical Characteristics

• ● Low contact resistance

• ● Very low leakage (especially with triaxial guarded versions)

• ● Not designed for high-frequency transmission

• ● Minimal concern about impedance matching

3.4 Advantages

• ● Simple and durable

• ● Low cost

• ● Suitable for all general semiconductor DC tests

• ● High stability and long lifespan

• ● Available in Kelvin (4-wire) configuration for accurate low-resistance measurements

3.5 Limitations

• ● Cannot support high-frequency measurements

• ● Parasitic capacitance and inductance distort signals beyond a few MHz

• ● Not suitable for S-parameter or impedance modeling

4. RF Probes

4.1 Purpose & Use Cases

RF probes are designed for high-frequency and radio-frequency device characterization, typically from MHz to 67 GHz, depending on the probe manufacturer.

Common use cases include:

• ● RF amplifiers

• ● VCOs / LNAs / mixers

• ● GaAs / GaN / SiGe RF devices

• ● On-wafer S-parameter measurements

• ● Characterization of high-speed digital I/O

• ● Impedance matching verification

4.2 Structure

RF probes have a completely different architecture from DC probes. Key elements:

• ● Coplanar waveguides (CPW) for 50-ohm transmission

• ● Multiple contact tips (typically GSG, GSGSG, or GS structures)

• ● Precision-aligned probe tip geometry

• ● Low-loss coaxial connector (e.g., K-connector, 2.92 mm, 1.85 mm)

• ● Calibration substrate support (ISS)

GSG (Ground-Signal-Ground) geometry is used to:

• ● provide return paths

• ● reduce crosstalk

• ● minimize parasitic inductance

4.3 Electrical Characteristics

RF probes are engineered for:

• ● Constant 50 Ω characteristic impedance

• ● Low insertion loss

• ● Low return loss

• ● Accurate S-parameter transmission

They minimize electrical parasitics through precise tip spacing and controlled CPW structure.

4.4 Calibration Requirements

RF measurements must be calibrated using industry standards such as:

• ● SOLT (Short-Open-Load-Thru)

• ● TRL (Through-Reflect-Line)

• ● LRRM

An RF calibration substrate (ISS) is mandatory for accurate results.

4.5 Advantages

• ● Accurate RF transmission up to 67 GHz

• ● Excellent repeatability

• ● Supports impedance-controlled measurements

• ● Suitable for RF/MMIC device characterization

4.6 Limitations

• ● More fragile compared to DC probes

• ● Sensitive to probe tip wear

• ● Requires careful calibration

• ● More expensive

• ● Not suitable for high-current DC tests

5. Microwave Probes

5.1 Purpose & Use Cases

Microwave probes operate from 20 GHz to 500+ GHz and are used in extremely high-frequency domains, including:

• ● 5G FR2 (28 GHz, 39 GHz)

• ● 6G research (100–300 GHz)

• ● Automotive radar (77–81 GHz)

• ● Terahertz imaging devices

• ● High-frequency photonics

• ● Ultra-fast digital devices (70–110 GHz)

These probes are a cornerstone of mmWave labs and advanced semiconductor R&D.

5.2 Structure

Microwave probes must minimize electrical loss at extremely high frequencies. Key design features include:

• ● Air-coplanar transmission lines (ACPL)

• ● Ultra-short tip length to reduce parasitic inductance

• ● High-precision GSG alignment (<1 µm tolerance)

• ● Waveguide or coaxial connector interface (1.0 mm, 0.8 mm, 0.6 mm)

• ● Low-loss substrate

Microwave probes are generally more compact and delicate than RF probes.

5.3 Electrical Characteristics

• ● Low insertion loss at >100 GHz

• ● Perfect 50 Ω impedance matching

• ● Near-zero dispersion in CPW structure

• ● Minimal parasitic capacitance

• ● Near-field transmission optimization

5.4 Advantages

• ● Supports extremely high frequencies (100–500 GHz)

• ● Suitable for cutting-edge communication and radar applications

• ● High precision and repeatability

• ● Essential for S-parameter, noise figure, and harmonic distortion tests

5.5 Limitations

• ● Very high cost

• ● Extremely fragile

• ● Requires ultra-stable probe stations (low-sway, thermal control)

• ● Requires advanced calibration (multi-line TRL, waveguide calibration)

• ● Sensitive to pad cleanliness and probe landing force

Conclusion

DC probes, RF probes, and microwave probes serve different purposes and are engineered for distinct electrical domains.

DC probes excel in low-frequency parametric testing.
RF probes are essential for accurate impedance-controlled RF measurements.
Microwave probes enable cutting-edge mmWave and 6G-ready research.

Selecting the correct probe is essential for:

• ● Measurement accuracy

• ● Device integrity

• ● Test repeatability

• ● Lab efficiency

• ● Long-term probe performance

Understanding the distinctions outlined in this guide ensures engineers can confidently select the best probe type for their application and avoid costly measurement errors.
